Almacén de estructura metálica de marco de acero ligero
Highlights
- Acero C/Z conformado en frío, 60% más ligero que el hormigón, 40% de ahorro en cimentación
- Luces libres de 15-36 m, carga de entreplanta hasta 5 kN/m²
- Preingeniería de muelle de carga y puerta superior
- Conexiones atornilladas: reubicables y ampliables
- Instalación de 20-30 días para almacén estándar de 1,500 m²
- Diseño estructural y lista de materiales gratuitos
Specifications
| Brand | Jidian Construction Materials Co., Ltd. |
|---|---|
| Product origin | Xiamen, Fujian, China |
| Building type | Portal frame construction (light steel) |
| Main steel | Q235/Q345 cold-formed C/Z-section + H-section |
| Max clear span | 15-36m |
| Eave height | 4-10m (customizable) |
| Roof load | 0.5-0.7 kN/m² |
| Mezzanine load | Up to 5 kN/m² |
| Cladding options | Corrugated steel sheet, rock wool/PU sandwich panel, ALC panel |
| Surface treatment | Galvanized Z275-Z350 + optional epoxy primer |
| Delivery time | 20-30 days after drawing confirmation |
| Supply capacity | 360,000 tons/year |
Product Detail
Warehouse Construction Challenges & Our Light Steel Solutiontion
Logistics operators and manufacturers need warehouses that are fast to build, cost-effective, and adaptable to changing storage requirements. Traditional concrete construction is expensive, slow, and permanent. Our light steel frame metal structure warehouse offers a lighter, faster alternative. Using Q235/Q345 cold-formed C-section and Z-section purlins with H-section portal frames, the structure achieves clear spans of 15-36m at a self-weight 60% lighter than equivalent concrete buildings. This reduces foundation costs by approximately 40%. For a standard 1,500 m² logistics warehouse, the complete steel frame installs in 20-30 days versus 4-6 months for masonry. The light steel frame is compatible with insulated sandwich panels for climate-controlled storage, or corrugated steel sheet for dry goods warehousing.
Product Advantages
• Lightweight cold-formed steel: C/Z purlins (grade Q235/Q345) reduce frame weight by 60% versus concrete, enabling simpler strip or pad foundations.
• Versatile cladding: Supports corrugated steel sheet for dry storage, or insulated sandwich panels for temperature-controlled warehousing.
• Loading dock integration: Frame pre-engineered for dock leveler pits, overhead door openings, and canopy extensions.
• Mezzanine capability: Steel floor deck systems support mezzanine storage loads up to 5 kN/m² for vertical storage optimization.
• Relocatable design: Bolted connections allow disassembly and re-erection at a new site if logistics operations relocate.
• Competitive pricing: Light steel framing requires 30% less steel tonnage than heavy portal frames for the same footprint, lowering material and freight costs.
Exhibition Track Record & International Projectsects
Jidian Construction Materials Co., Ltd. has showcased warehouse and logistics building solutions at major international exhibitions including the China Import and Export Fair (Canton Fair), Poland BUDMA, Mexico ExpoCIHAC, Chile Edifica, Pakistan Build Asia, Capac Expo Habitat (Panama), The Philippines Building and Construction Exposition, and BuildTech Asia (Singapore). These exhibitions connected us with logistics operators and warehouse developers from Southeast Asia, Latin America, and Africa, resulting in warehouse projects exported to the Philippines, Indonesia, Pakistan, and Chile.
About Jidian Construction Materials Co., Ltd.
Founded in 2012 and headquartered in Xiamen, Fujian, China, Jidian Construction Materials Co., Ltd. is a leading steel structure manufacturer with over 12 years of industry experience. Our production facility operates advanced heavy and light steel production lines plus sandwich panel lines, staffed by a dedicated engineering team. Annual capacity reaches 360,000 Tons Steel Capacity and 1,000,000 m² Enclosure Output. We hold ISO9001, ISO14001, ISO45001, CE (EN1090), SGS, and BV certifications, plus China's highest Steel Structure Manufacturing Special Level Qualification. Warehouse and logistics building projects have been delivered to 50 Countries Covered across Europe, the Middle East, Southeast Asia, Africa, and the Americas, with 2,000+ Completed Projects worldwide.ide.
Service & Supportport
Pre-sales: Free site assessment, structural design, and material takeoff based on your storage type and local climate. Quotation within 24 hours.
Manufacturing: Automated roll-forming for purlins, CNC cutting and SAW welding for frame components. Weekly production photos.
Installation: Assembly manuals, video guides, and remote technical support included. On-site engineer available for projects above 1,500 m².
After-sales: 1-year warranty, 24/7 support hotline, lifetime spare parts supply.
Packaging & Deliveryvery
Steel components are bundled with steel straps and fabric-wrapped at ends; small parts are packed in iron boxes. Standard shipments use 40ft OT or 40ft HQ containers. HQ containers use steel pallets for faster loading/unloading; OT containers are loaded piece by piece by crane. Delivery time: 20-30 days after drawing confirmation.
FAQ
Q: What is the minimum order quantity?
A: No strict MOQ. We accept orders from a single warehouse (200 m²) upward. Unit cost decreases significantly above 500 m².
Q: Can the warehouse support a mezzanine floor?
A: Yes. Steel floor deck systems support mezzanine storage loads up to 5 kN/m² for vertical storage optimization.
Q: Can the warehouse be disassembled and moved later?
A: Yes. All connections are bolted, enabling disassembly and re-erection at a new location with minimal material loss.
Q: What insulation options are available?
A: 50-100mm EPS, rock wool, or polyurethane sandwich panels. We recommend rock wool for fire-sensitive storage and EPS for budget-conscious projects.
Q: Can I put my logo on the warehouse components?
A: Yes. We can laser-cut or paint your logo on designated steel components and packaging.
Q: Can I request OEM manufacturing?
A: Yes. We offer full OEM/ODM services including custom branding on components, packaging, and documentation.
Q: What are the payment terms?
A: T/T (30% deposit, 70% before shipment) or L/C at sight. Trade assurance supported via Alibaba.
Q: Do you provide samples for quality verification?
A: Yes. We can send galvanized steel samples and cladding panel samples by express for your quality verification before placing a bulk order.
